NOSHOK 2200 Series Digital Indicator

• Input signals available:
  • 4 to 20 mA
  • 0 to 10 VDC (others ranges available)
  • Thermocouple (Type J, K, T or E)
  • RTD PT100
• Universal AC/DC power input
• Accuracy:
  • <0.03% F.S. 64 to 82°F
  • <0.12% F.S. 32 to 122°F
• Display:
  • Upper; 6 digit, 0.71in tri-color LED
  • Lower; 9 digit, 0.35in green LED
• NEMA 4 enclosure option
• 24 Vdc sensor excitation
• Built-in USB port

The NOSHOK 2200 Series Digital Indicator accepts a wide variety of input signals including thermocouples or RTDs, current,
voltage, resistance and process signals. The 2200 has a universal AC/DC power input and 24 VDC sensor excitation. The 2200
is also provided with a built-in USB port for configuring with a computer. A variety of plug-in card are available.

Applications include:

• Pump control and monitoring
• Liquid level measurement
• Heating and cooling
• Force measurement
• Cycle counting
• Flow rate measurement
