Dwyer ASG Signal Generator

• Impedance
  • Voltage: 1000Ω min
  • Current: 300Ω max
• Output: 0 to 20 mA (2 mA increments); 0-10 VDC (1 VDC increments)
• Resolution: 1 mA (current); 1 VDC (voltage)
• Large Backlit Display
• Timed Ramp Function
• Process Display Configuration
• Transmitter Calibration
• Ramping Time Intervals: 1 to 20 sec (1 sec increments)
• Auto Power Off
• 9 V alkaline battery, user replaceable or 120 VAC
• Electrical Connections: 6 ft (1.8 m) with alligator clips

The Dwyer ASG analog signal generator is a pocket-sized instrument ideal tool for troubleshooting transmitters, transducers, motors and actuators. The unit generates a 0 to 10 VDC signal in increments of 1 volt or a 4 to 20 mA signal in increments of 2 mA. An LED bar graph visually indicates analog signal level. The model ASG will also continuously ramp to user defined maximum and minimum values with user defined ramp interval timing.
